1.Unique waste collection structure
Based on the new structure design, YS-SL6060 uses innovative waste and smoke collection system, which completely frees customers from "equipment stabilization killers" such as chips, slag, iron dust and so on. It greatly improves the service life and stability of the equipment.
2.High Power Fiber Laser
YS-SL6060 is a semiconductor-pumped solid-state high-power fiber laser with advanced technology. Increasing the cutting efficiency also greatly increases the types of Machinable products. It is easy to deal with both ordinary metal sheets and precise parts with a certain thickness.
3.Provide users with specialized process solutions
Professional fixture design, can adapt to a variety of sizes, shapes of materials, so that every minute of production belongs to laser cutting. This is not only a device, but also a set of equipment process system that can optimize the user's process and give full play to the maximum value of the equipment.
| Technicals | Parameters |
| Model | YS-G680 |
| Cutting speed | Ordinary：15000pads/h~~~Hig：24000pads/h |
| Cutting area | 680mm*680mm |
| Cutting thickness | 0.02mm~0.5mm |
| Positioning accuracy | ±0.002mm |
| Repeat positioning accuracy | ±0.002mm |
| Efficiency | 100W |
| Operation software | SuperCut-AL |
| Machine size | 1500mm(L)*1600mm(W)*1500mm(H) |
| Maximum size of clamping net frame | 780mm*1500mm*40mm |
| Maximum clamping steel sheet size | 820mm*700mm |
| Max length of cutting stencil | 1500MM |
| Focused spot diameter | 20±5um |
| Laser source | FibeLaser |
| Beam quality | M2＜1.1 |
| Laser Wavelength | 1090nm |
| Ambient temperature | 20±2℃ |
| Ambient humidity | ＜60% |
| Soft-hard wares | Include one set of PC and CAM software |
| Compatible file | Gerber,DXF |
| Power | Single phase 220V/3KW，50/60HZ.10A |
| Auxiliary gas | Industrial Oxygen-Compressed Air |
| Air press | 8~12bar |
| Machine body | marble |
| Machine weight | 3000KG |
